MB1222 PLC Controlled Paper Cup Machine

Description
MB-12/22 fully automatic PLC controlled paper cup machine is a new type of paper cup making machine utilizing technology of foreign high speed paper cup machine. This high speed paper cup making machine is patent equipment in China. Main parts of it include ultrasonic sealing head for paper cup side welding, hot air system for the bottom, touch screen, PLC controller, motor, paper cup deliver system and alarm system. It is suitable for making various paper cups, especially tall cups.

Features of PLC Controlled Paper Cup Machine
1. With two turntables, it is an upgrading and updating machine of existing three turntables equipment, which decreases the machine's working stroke.
2. The machine can work stably in high speed operation.
3. This high speed paper cup making machine has functions of automatic discharging, counting and stacking.
4. This paper cup machine has automatic oiling and lubricating system.
5. It features non-chain transmission and touch screen programming.
6. MB-12/22 fully automatic PLC controlled paper cup machine is easy to operate.

Parameters PLC controlled High Speed Paper Cup Making Machine
Paper Cup Specification 6 to 32 (oz)
Paper Material 150 to 400 (gsm)
Output 60 to 80 (pcs/min)
Power Requirement 380 V 50 Hz
Total Power 13 kW
Air Consumption 0.4 m?/min
Machine Weight 2200kg
Overall Dimension 2800 ?? 1600 ?? 1600 (mm)
Maintenance
Please refer to operation manual before operating PLC controlled paper cup machine.

Packaging
Items are packed by wooden case and delivered by sea.

Ruian Mingbo Machinery Co., Ltd. is a professional manufacturer of high speed paper cup making machines in China. Mingbo has been engaged in producing PLC controlled paper cup machine, paper bowl making machine, paper bucket making machine, paper plate making machine, die cutting machine, cup lid making machine, flexo printing machine, paper lunch box making machine, etc.
